 PT-150/170 PH |
* Built in Intel945GM FSB667 IPC
* 15" 17" A grade LCD with touch
* Up to Core 2 Duo Socket M CPU
|
|
|
- Specification
- Feature & Photo
- Application
- View 3D Animation
| Type |
System |
| Product Name |
PT-150/170 PH |
| Monitor Size |
15"; 17" |
| Touch Panel |
Taiwan 5W Resistive |
| CPU |
Intel C2D T5500(1.66GHz) |
| Chipset |
Intel 945GM+ICH7M |
| Memory |
1GB DDRII/667; up to 4GB |
| Storage Device |
80GB, 2.5" HDD SATA |
| Lan |
Dual GbE |
| VGA Port |
1 |
| Serial Port |
1 |
| Parallel Port |
|
| USB Port |
4 |
| RJ-45 |
2 |
| Audio Jack |
1 |
| Expansion Slot |
|
| Power Supply |
Internal 125W power |
| Dimension |
15inch 327(W) x416(H) x 92(D) mm |
| Optional Device |
* Industrial MDM
* ELO 5W resistive touch
* Mini PCI WiFi module
|
| |
|
|
