 FW-i3/i5/i7 (15"~23.8") |
* FW-15: 15", 1024x768
* FW-16: 15.6", 1366x768
* FW-17: 17", 1280x1024
* FW-18: 18.5", 1366x768
* FW-19: 19", 1280x1024
* FW-21: 21.5", 1920x1080
* FW-23: 23.8", 1920x1080 |
|
|
- Specification
- Feature & Photo
- Application
- View 3D Animation
| Type |
System |
| Product Name |
FW-i3/i5/i7 (15"~23.8") |
| Monitor Size |
15" ~ 23.8" |
| Touch Panel |
Taiwan 5W Resistive or P-CAP |
| CPU |
Intel KabyLake or SkyLake |
| Chipset |
Intel HD Graphics |
| Memory |
4GB DDR4 up to 16GB |
| Storage Device |
2.5" 120GB SSD; 2.5" 500GB HDD |
| Lan |
2 |
| VGA Port |
HDMI+Display port |
| Serial Port |
2xDB-9 |
| Parallel Port |
|
| USB Port |
4xUSB3.0 |
| RJ-45 |
1 |
| Audio Jack |
|
| Expansion Slot |
|
| Power Supply |
96W |
| Dimension |
|
| Optional Device |
Scanner
Wireless LAN
Metal Stand
IP66 / IP69K
|
| Remark |
* Operating Temperature: 0°C~50°C (32°F~122°F)
* Storage Temperature: -20°C~50°C (-4°F~122°F)
* Relative Humidity: 10%~95% @40°C (non-condensing) |
| |
|
|
